Slab Crab Model Specs
| SLAB CRAB BUCKET WIDTHS | BUCKET WEIGHT | BUCKET WIDTH | SLAB THICKNESS DATA | NUMBER OF BUCKET TEETH | BUCKET SPECS |
| 36″ | 1950 Pounds | 36 Inches | 4 – 12 Inches | 3 | Click to View 36″ Slab Crab |
| 42″ | 2450 Pounds | 42 Inches | 4 – 12 Inches | 4 | Click to View 42″ Slab Crab |
| 42″ Wide Mouth | 2610 Pounds | 42 Inches | 4 – 16 Inches | 4 | Click to View 42″ Wide Mouth Slab Crab |
| 48″ | 2610 Pounds | 48 inches | 4 – 12 inches | 4 | Click to View 48″ Slab Crab |
| 54″ | 5380 Pounds | 54 Inches | 4 – 21 Inches | 5 | Click to View 54″ Slab Crab |
All weights listed are for the bucket shell without lugging. Overall weight will be slightly more once lugged for the machine. These are standard models that have a quick turnaround time. Custom concrete slab lifter models are also available to accommodate thicker slabs and constricted demolition projects. Contact Kenco for a custom quote.
Available Slab Crab Models by Machine Class
| WEIGHT CLASS of MACHINE | OPERATING WEIGHT RANGE | POSSIBLE MACHINES | SLAB CRAB OPTIONS |
| EX200 | 40,000 – 50,000 lbs | CASE CX210, CX225, CX235 CAT 318, 320 Doosan DX210, DX225 Hitachi ZX200, ZX210, ZX225 Hyundai R210, R235 John Deere 200, 210, 220, 225 Kobelco SK210, 215SR, 235SR Komatsu PC200, PC220, PC228 Volvo EW/EC210, EC235, ECR235 | 36″ |
| EX250 | 50,001 – 65,000 lbs | CASE CX240, CX250, CX290, CX300 CAT 321, 322, 324, 325, 328, 329 Doosan DX255, DX300 Hitachi ZX240, ZX270 Hyundai R250, R290, R305 John Deere 240, 250, 270, 290 Kobelco SK260LC, SK295LC Komatsu PC270, PC290 Volvo EC240, EC290, EC300, EC305 | 36″ 42″ |
| EX300 | 65,001 – 80,000 lbs | CASE CX330, CX350 CAT 330, 336 Doosan DX350 Hitachi ZX350 Hyundai R320, R360 John Deere 350 Kobelco SK350LC Komatsu PC300, PC308, PC350, PC360 Volvo EC330, EC340, EC360 | 42″ 42″ Wide Mouth 48″ |
| EX400 | 80,001 – 95,000 lbs | CASE CX460, CX470 CAT 345 Doosan DX420, DX480 Hitachi ZX450 Hyundai R380, R400, R450 John Deere 450 Kobelco SK485LC Komatsu PC400, PC450, PC490 Volvo EC460, EC480 | 54″ |
